The original Heavy Duty Booster Pump, designed for high flow at high head.
The HT Series Booster Pumps are built to withstand the rigorous demands
generated through use in DESALINATION of the Reverse Osmosis,
Deionization, Car wash, Washdown and Booster Lift Station applications, as well as
various other Industrial and Agricultural uses.

Features And Benefits

• Available in both Stainless Steel 316L
• Heavy duty 7/ 8” diameter stainless steel shaft with a double keyway.
• High strength, glass filled Noryl impellers precision machined for dimensional
  stability and efficiency.
• Mechanical seals are stainless steel constructed with Viton elastomers on stainless steel models.

WEBTROL HT-SERIES HIGH PRESSURE BOOSTER PUMP SPECIFICATION :

INLET & DISCHARGE HOUSING : 316L
PUMP HOUSING                       : 316L
IMPELLER & DIFFUSER              : NORYL
SHAFT BEARING & COUPLING    : 316L
MECHANICAL SEAL                   : RULON
MECHANICAL SEAL SPACER       : 316L
O-RING                                    : VILON

TYPE :     FLOW RATE :       PRESSURE:     MOTOR POWER :

HT-60          200 LPM             < 750 PSI       22 KW x 380V x 50Hz

COUNTRY ORIGINAL : U.S.A
